Application of FPL-1518-4 Feipula woodworking engraving machine range:

The classical mahogany furniture carving, antique carved furniture, wooden crafts relief carving, wooden frames, wood carving, musical instruments, gift boxes, jewelry boxes and other wood bas relief processing, can realize multi head processing, improve processing efficiency. Suitable materials: hardwood, wood, acrylic, horn, marble, copper and aluminum and other nonferrous metals.

FPL-1518-4 woodworking engraving machine performance summary:

Multi head engraving machine is designed for mass production, high precision ball screw drive, stable performance and high precision.

The whole machine adopts the steel structure, the rigidity is not deformed, the working table top backing plate, the strength is big.

The main shaft adopts the dust and water proof high power frequency conversion water cooling motor, the noise is small, strong and powerful, maintenance free, and can realize continuous operation.

Intelligent processing cross-border protection, to prevent mechanical collision phenomenon caused by the over processing format layout design.

Intelligent high-speed module high-speed operation, can achieve power outage recovery, breakpoint continued carving, the next day processing, convenient and labor saving.

FPL-1518-2, FPL-1518-3, FPL-1518-4 detailed parameter configuration:

Model FPL-1518-3 FPL-1518-4 FPL-1518-2

Covers an area of 1.8m*2.4m*1.5m 1.8m*2.4m*1.5m 1.8m*2.4m*1.5m

X travel 500mm*3 375mm*4 750mm*2

Y travel 1800mm 1800mm 1800mm

Z travel 120mm 120mm 120mm

The table structure of aluminum clamping table aluminum clamping table aluminum clamping table

Drive mode high precision screw drive high precision screw drive high precision screw drive

The commonly used 3 - 12.7 of the diameter of the handle of the 3 - 12.7 3 - 12.7 of Phi Phi

Positioning accuracy 0.02mm 0.02mm 0.02mm

Optional spindle power -4.5kw 1.5kw -4.5kw 1.5kw -4.5kw 1.5kw

Working voltage 220v/50Hz 220v/50Hz 220v/50Hz

Working mode step / servo step / servo step / servo

Spindle speed 0-24000rpm/min 0-24000rpm/min 0-24000rpm/min

Maximum operating speed 12000mm/min 12000mm/min 12000mm/min

Shanghai Weihong engraving machine dedicated operating system system of Shanghai Weihong engraving machine engraving machine for special system of Shanghai Weihong system

Note: equipment processing table size can be more customer requirements! Specifications are subject to change without prior notice (configuration to the contract shall be subject to the weight of the actual shipment).

Optional accessories:

1, dust cleaning device

2, setting device

3, vacuum adsorption device

4, the number of free choice of spindle

5, servo motor

Woodworking engraving machine in the advantage of the furniture industry

1, mechanical equipment, higher than the artificial production efficiency, and very low waste rate. The structure of Longmen type woodworking engraving machine, heavy steel structure to ensure the overall stability of the machine bed.

2, rack drive, smooth transmission, to ensure long high-speed operation is not deformed, do not shake. This carved wooden doors of the time, you can guarantee the accuracy of the engraving and beautiful, so as to greatly improve the efficiency of the production of wooden doors.

3, the traditional handmade wooden door production, many times by the influence of artificial factors, low yield, high cost. Now using wood engraving machine production of wooden doors, carved picture is more delicate, and suitable for mass production.
